CASIC HW-310A MUTIPURPOSE FIXED-WING UAV

INQUIRY
Description

Product Overview

  • HW-310A UAV system, as a kind of multi-purpose, small- sized, mid-low altitude, low-speed unmanned flight platform, adopts push-back twin-boom aerodynamic configuration. With convenient change of payloads such as visible light/IR photoelectric pod, aerial camera, etc, it can execute monitoring, aerial photography, aerial survey and other missions.



  • High control precision
    High reliability
    Mature space technology
    Gimbaled EO or IR or LRF or LA Payload
    High maneuverability
    Modular design
  •
Specifications
  • UAV dimensions (length×wingspan×height) 3.10m×4.60m×0.99m
  • Ceiling 3000m(sea level)
  • Max. telemetry and control distance 50km
  • Cruise speed 100km/h-120km/h
  • Max. speed 130km/h
  • Endurance 4h-6h
  • Max. take-off weight 75kg
  • Max. mission payload 15kg
  • Navigation mode Combined navigation
  • Propulsion system One double-cylinder piston engine
  • Take-off mode Wheeled
  • Recovery mode Wheeled or parachute
